Water cyclone separator
Factory direct sales:Yes
Delivery method:Sea/land
Brief Introduction:Introduction Hydro-cyclone is a kind of equipment for classifying the ore pulp by use of centrifugal force. It has no motion and dynamic parts,and needs to be matched with corresponding slurry pump. It is mainly used in ore dressing industr
Hotline +8613607653853
-
Introduction -
Technical Data
Introduction
Introduction
Hydro-cyclone is a kind of equipment for classifying the ore pulp by use of centrifugal force. It has no motion and dynamic parts,and needs to be matched with corresponding slurry pump. It is mainly used in ore dressing industry for classifying, dewatering and desliming.
Hydro-cyclone is a kind of equipment for classifying the ore pulp by use of centrifugal force. It has no motion and dynamic parts,and needs to be matched with corresponding slurry pump. It is mainly used in ore dressing industry for classifying, dewatering and desliming.
Hydro-cyclone has been extensively used for closed circuit grinding and classification system , thickening, desliming, dewatering , tailings filling, damming, recovery processes in ferrous, nonferrous metal and nonmetal mine industries, and is deeply popular with customers due to high classification efficiency, simple structure, large throughput, and small occupied area.
Working principle
In closed circuit grinding system, it features high classification efficiency and fine over fall fineness under high mine concentration. Classification efficiency is higher for 5-10% than common screw grader. It benefits for enhancing grader utilizing coefficient. Choose proper specification and mode of cyclone according to grinding processing capacity, over fall fineness and sedimentation concentration.
Technical Data
Technical parameter
| Model |
Diameter (mm) |
Overflow Pipe Dia.(mm) |
Bottom Exit Dia.(mm) |
Cone Angle (°) |
Max. Feeding Size(mm) |
Capacity (m³/h) |
Classify Size(µm) |
| FX500 | 500 |
130, 140, 150, 160, 180, 220 |
35, 45, 50, 65, 70, 80, 90, 100 |
10 20 25 |
10 | 140-220 |
74-200 74-200 74-150 |
| FX350 | 350 |
80, 90, 105, 115, 120 |
30, 35, 40, 45, 50, 60, 70 |
15 20 25 |
6 | 60-105 |
50-150 50-150 50-120 |
| FX300 | 300 |
55, 65, 80, 100, 120 |
20, 25, 30, 35, 40 |
15 20 25 |
5 | 45-90 |
50-120 50-150 50-150 |
| FX250 | 250 |
60, 75, 80, 100, 120 |
16, 18, 20, 25, 30, 35, 40 |
10 15 20 |
3 | 40-65 |
40-100 40-100 30-100 |
| FX200 | 200 |
40, 50, 55, 60 |
16, 20, 24, 28, 32 |
15 20 |
2 | 25-40 |
40-100 10-100 |
| FX165 | 165 |
40, 50, 55, 60 |
30, 35, 40, 45, 50 |
20 6 |
1.5 | 20-30 | 40-90 |
| FX150 | 150 |
30, 35, 40, 45, 50 |
8, 10, 12, 14, 16, 18, 20, 22 |
8 15 20 |
1.5 | 11-20 |
30-74 30-74 20-74 |
