Dust collector / Bag dust filter

Dust collector / Bag dust filter

Service Online

Factory direct sales:Yes

Delivery method:Sea/land

Brief Introduction:Product introduction Bag-Type dust remover is a kind of dry dust filter device,It is suitable for trapping fine, dry and non fibrous dust.In recent years, due to the emergence of new synthetic fiber filter material, the continuous improveme

Hotline +8613607653853

Introduction

Product introduction
Bag-Type dust remover is a kind of dry dust filter device,It is suitable for trapping fine, dry and non fibrous dust.In recent years, due to the emergence of new synthetic fiber filter material, the continuous improvement of ash removal method and the use of automatic control and detection device make the pulse dust collector develop rapidly, which has become the most competitive dedusting equipment in all kinds of high-efficiency dedusting equipment.



Technical Data

Model QM QM QM QM QM QM QM QM QM
32-3 32-4 32-5 32-6 64-4 64-5 64-6 64-7 64-8
Volume of processed Air
 (m3/h)		 6900 8930 11160 13390 17800 22300 26700 31200 35700
Filter wind speed
(M/min)		 0.8-2.0(Customize according to technological conditions)
Total filtration Area
 (m2)		 93 124 155 186 248 310 372 434 496
NET filtration area
 (m2)		 62 93 124 155 186 248 310 272 434
Number of
filtration rooms		 3 4 5 6 4 5 6 7 8
Total number of
 filter bags		 96 128 160 192 256 320 384 448 512
Resistance Dust
 (PA)		 1470-1770
Concentration of
inlet gas dust (g/Nm3)		 <200       ＜1000
Concentration of
exhaust gas dust (g/m3)		 <0.1
Pressure on the body of
the dust collector (Pa)		 5000
